Solidity Gas Optimization: What Saves Gas and What's Folklore

The first version of this post got several things wrong, and two of them are classics. View functions “don’t consume any gas when called externally”: they do, the moment another contract calls them. Unsigned integers “take up less space and are cheaper”: they’re the same 32 bytes, and in the case where uints did win in my tests, it was for a different reason. Most gas advice is like that. It gets repeated because it sounds right, not because somebody measured it.

So this time I measured. Every number below comes from a real transaction, and the tricks that save nothing are marked as such.

Where Does Gas Actually Go in a Solidity Contract?

Think of gas as an itemized bill. Every opcode is a line item, and the transaction receipt shows the total. Most gas tips argue over the bread basket, when the expensive items are a short list. These are the current mainnet prices:

Read that table once and most of this post follows from it. Storage is the steak. Arithmetic is tap water. A loop that reads the same storage slot 100 times pays 2,100 once and 100 for each read after that, while the ADD inside the loop costs 3. Shaving arithmetic while you hit storage is optimizing the wrong line.¹

How Did I Measure These Numbers?

I compiled each contract with solc 0.8.37 (optimizer on, 200 runs, legacy pipeline, the setup most projects ship with) and ran signed transactions in an in-memory EVM (@ethereumjs/vm 10.1.3, Prague rules). Each comparison gets a fresh contract plus one warm-up call before the measured one, so a first write to an empty slot doesn’t skew anything. The numbers are receipt gasUsed, which includes the 21,000 base cost and calldata, after refunds.

Here’s the whole bill in one table. The sections after it explain each line.

Which Solidity Gas Optimizations Are Worth It?

Cache storage reads in local variables

This is the biggest line on the bill that you control directly. The naive loop reads arr.length, fee, and total from storage on every pass and writes total back every time:

1
// 321,381 gas for 100 items: storage on every iteration
2
for (uint256 i; i < arr.length; ++i) total += arr[i] * fee;
3

4
// 280,347 gas: read once, work in memory, write once
5
uint256 len = arr.length;
6
uint256 f = fee;
7
uint256 t = total;
8
for (uint256 i; i < len; ++i) t += arr[i] * f;
9
total = t;

Warm reads cost 100 each, so this saves about 400 gas per iteration, not thousands. It adds up anyway: 41,034 gas over 100 items, 12.8% of the transaction. Slither flags the arr.length case with its cache-array-length detector.²

Use calldata for array and struct parameters you don’t modify

A memory parameter makes the contract copy the whole array out of calldata before your code even starts. calldata reads it in place. Summing 100 uint256s cost 64,402 gas with public and memory, and 56,860 with external and calldata. That’s a 7,542 gas difference, and it grows with the array.

This is where the old “external is cheaper than public” advice comes from, and the advice has the cause wrong. Visibility isn’t the lever. A public function can take calldata parameters too (since Solidity 0.6.9), and then it costs the same: 56,860 gas, to the unit. For non-array arguments, visibility makes no difference at all, as the myths section shows.

Replace revert strings with custom errors

1
error NotOwner();
2

3
// 21,367 gas when it reverts, and the string sits in your bytecode
4
require(msg.sender == owner, "Ownable: caller is not the owner");
5

6
// 21,266 gas, and the error is a 4-byte selector
7
if (msg.sender != owner) revert NotOwner();
8
require(msg.sender == owner, NotOwner()); // 0.8.27+, 21,288 gas

At runtime this saves about 100 gas, and only when the call fails. The deploy is where it shows up. A contract with three owner-checked functions shrank from 249 to 198 bytes of runtime code and cost 11,014 gas less to deploy. Custom errors arrived in 0.8.4, and require(bool, Error) works on the default pipeline since 0.8.27 (0.8.26 had it for via-IR only).³ There’s no reason left to write a new revert string.

Mark values that never change as constant or immutable

Reading a storage variable costs 2,100 gas the first time in a transaction. A constant is inlined into the bytecode at compile time, and an immutable gets written into the code at deploy time. In my test, one read cost 25,588 gas from storage, 23,519 as immutable, and 23,508 as constant. Slither’s constable-states and immutable-states detectors find candidates for you. The details of each, including the 32 bytes every immutable reserves, are in constant vs immutable in Solidity.

Pack storage variables into fewer slots

A new slot costs 20,000 gas to write, so two uint128s that share one slot halve that bill. The rules (declaration order, structs starting a fresh slot, the masking cost of small types) are in how storage slot packing saves gas. I won’t repeat them here.

Use transient storage for values that only live during one transaction

EIP-1153 shipped with Cancun (the Dencun upgrade, March 13, 2024). It adds TSTORE and TLOAD at 100 gas each, on storage that’s wiped at the end of the transaction. The textbook use is a reentrancy lock, which is set and cleared within the same call anyway. Swapping OpenZeppelin’s ReentrancyGuard for ReentrancyGuardTransient (in Contracts since 5.1) saved 1,905 gas per guarded call.

Since 0.8.28 you can declare value-type state variables transient directly:⁴

1
contract Router {
2
    bool transient locked; // gone when the transaction ends, no refund games
3

4
    modifier lock() {
5
        require(!locked, "reentrant");
6
        locked = true;
7
        _;
8
        locked = false; // clear it anyway: composability footgun otherwise
9
    }
10
}

The compiler warns you about the catch, and it’s right. Transient storage is cleared at the end of the transaction, not at the end of your call, so if you leave a value set, a second call into your contract in the same transaction sees it. Clear what you set.

Emit events for data no contract reads

Contracts can’t read events, but indexers and front ends can. If a record exists only so your UI can show history, storing it is ordering the most expensive dish on the menu for a guest who never shows up. Writing a 32-byte record to a new mapping slot cost 44,141 gas, and emitting it in an indexed event cost 23,411. That’s 20,730 saved per record. The test is simple: if no contract will ever read the value, don’t store it.

Which Gas Tips Are Myths?

Myth: Unsigned integers are cheaper because they take less space

The reason usually given is wrong. Both uint256 and int256 are one 32-byte word, and the signed opcodes cost what the unsigned ones do (SDIV is 5 gas, same as DIV). Inside unchecked, my loop doing multiply and divide cost 29,253 gas with uint256 and 29,209 with int256. A dead heat.

Turn checked arithmetic back on and int256 loses: 61,931 against 49,175, about 26% more. The overflow checks for signed multiply and divide need extra cases (like type(int256).min / -1), and you pay for them on every operation. So use uint for values that can’t go negative. The real win is that you’re telling the compiler the truth about the value, and the cheaper checks come along with it.

Myth: View and pure functions don’t cost gas

They’re free only when you call them off-chain with eth_call, because no transaction happens. Call a view function from inside a transaction and it’s billed like anything else. My test contract that read a value through another contract’s view function paid 28,536 gas, against 23,422 for the same write with no call. The 5,114 difference is mostly the 2,600 cold address access and the 2,100 cold storage read.

Myth: Internal functions are cheaper than external ones

Calling an internal helper cost 23,877 gas, and calling a public one from inside the same contract cost 23,876. Same code, same jump. (Add a few functions to the contract and those numbers drift by about 20 gas either way, because the dispatcher checks function selectors in order. That’s noise, not visibility.) The cost appears when you call your own function as this.f(), which turns a jump into a real message call (610 more gas here, and more when the address isn’t already warm), or when array arguments get copied to memory. Pick visibility for your API, not your gas bill.

Myth: Write unchecked { ++i; } in every loop

This was good advice until October 2023. Solidity 0.8.22 removes the overflow check on a loop counter by itself when the loop has the form for (uint256 i; i < n; ++i), even with the optimizer off.⁵ Over 1,000 iterations, the hand-written unchecked block saved 22 gas, and i++ cost 22 more than ++i. Rounding error.

The check does stay when you write i <= n, which only < qualifies for. That version cost 205,714 gas against 146,672, so if you want a free 29% on a hot loop, write <. (Solhint’s gas-increment-by-one and gas-strict-inequalities rules still flag the ++i style. One of those two rules matters on 0.8.22+, and it’s the second one.)⁶

Myth: Optimizing gas shrinks your carbon footprint

Not since the Merge on September 15, 2022. Proof of stake cut Ethereum’s energy use by an estimated 99.95%, and validators don’t burn more electricity because your transaction used more gas.⁷ Optimize for your users’ wallets.

Myth: Gas tokens and storage refunds can pay for your transaction

That trick died with London in August 2021. EIP-3529 capped refunds at one fifth of the gas a transaction uses and cut the refund for clearing a slot to 4,800.⁸ Zeroing storage you no longer need is still polite, but it won’t pay for your transaction.

Do Compiler Settings Matter More Than Code Tricks?

Often, yes. Here’s OpenZeppelin’s ERC-20 (Contracts 5.7.0), byte for byte the same source, under four compiler settings:

The runs value tells the optimizer how often you expect each opcode to run. A high value trades a bigger deploy for cheaper calls, and here a million runs bought 142 gas per transfer for 113,234 more at deploy. That pays off after about 800 transfers. For a token people will move millions of times, worth it. For an internal admin contract, no.

The bigger lesson is the first row. With the optimizer off, my 1,000-iteration loop cost 267,865 gas instead of 146,672. If your gas report runs on unoptimized builds, you’re tuning against numbers you’ll never ship. That’s easier to get wrong than it sounds: Hardhat 3 runs tests on its default build profile, which is set up for development speed, while Ignition deploys with production, which turns the optimizer on.⁹ Measure with the settings you deploy with.

via-IR won every line in this test, but it’s still opt-in. The legacy pipeline remains the default, and making via-IR the default is still on the Solidity team’s roadmap.¹⁰ It compiles slower, and stack traces through its optimizer are harder to read. Try it, measure it, and keep it if your tests pass.

How Do Gas Limits Break Loops?

A loop over an array that anyone can grow has a ceiling. Since Fusaka (December 3, 2025), EIP-7825 caps a single transaction at 16,777,216 gas, even though a block now holds 60 million.¹¹ A loop that “fits in a block” can still fail to fit in a transaction, and from that day on the function can’t run at all. Bound your loops or process them in batches. If the loop sends ETH, use the pull over push pattern instead. Searching an array for a value is the same problem in slow motion; that’s what mappings are for.

What Changes on an L2?

The bill gets a second section. On an OP Stack chain, your fee is L2 execution gas plus an L1 data fee, and the L1 part is computed from an estimate of your transaction’s compressed size times Ethereum’s base fee and blob base fee.¹² Execution gas on L2 is cheap. Bytes you post to L1 are what cost money.

That changes what’s worth optimizing. Cold storage reads matter less on an L2 than on mainnet, and calldata size matters more: tightly packed arguments, fewer zero-padded uint256s where a uint64 would do, batching several actions into one transaction. Check the fee formula of your specific chain, because Arbitrum and the ZK rollups each price data their own way.

Which Tools Measure Solidity Gas Usage?

Measure before and after every change. In Foundry, forge test --gas-report prints a per-function table and forge snapshot writes a baseline you can diff in CI. Hardhat 3 has --gas-stats built into npx hardhat test, and the hardhat-gas-reporter plugin still works if you’re on Hardhat 2. Remix shows an estimate per transaction, good enough for a quick check.

For finding candidates, Slither’s optimization detectors (cache-array-length, constable-states, immutable-states, var-read-using-this) catch the obvious ones in seconds. Solhint has a gas rule set too. Mythril doesn’t belong on this list, although the first version of this post put it there: it’s a symbolic execution tool that looks for security bugs, not gas waste.

My Take

Start with storage, because that’s where the money is. Cache reads, move write-only records into events, mark constants, and pack slots. Then check your compiler settings, which can beat all of that combined. Skip the micro-tricks that 0.8.22 made obsolete.

And don’t trust a gas tip you haven’t measured. That includes this post. Run forge test --gas-report on your own contract before and after each change, and believe the receipt.
